SPS System for Research & Development LABOX Series
General Catalogue ![General Catalogue](img/sales/e_genecatalog.gif)
Features
- Originally developed Inverter type DC pulse generator greatly reduces electric
power consumption compared with the conventional SPS systems. It enables
the making of higher quality samples in less energy.
- The pressurizing mechanism equipped with the fast-responding AC servo motor realizes the precise control and low noise design of pressurizing force that are difficult to realize by the conventional hydraulic system.
- Freely setting of parameters, such as temperature, up-and-down speed of temperature, pressurizing force and holding time, permits the high-repeatable and precise control.
- It has the special energization mechanism enabling high-speed temperature
rise-100 ℃ to more than 500℃ per minute and high cooling performance. These
futures realize more speedy specimen making than conventional methods,
such as Hot press, HIP and Atmospheric sintering.
- We can design the system with the concept of controllability, workability and safety, as we introduced touch panel and various interlock functions and consider easy maintenance. This design allows even beginners to make high quality specimen.
- Space saving and light weight design.
Tabletop Type SPS System
Supporting Tool for Basic Experiments of Research & Development
![](img/e_prd_img1.jpg) |
![](img/e_prd_img2.jpg) |
![](img/e_prd_img3.jpg) |
LABOX-110 (table is not included) |
LABOX-350 (with optional unit) |
Small size samples of various materials
|
|Main Specification|
Model Name |
LABOX-110
|
LABOX-125 |
LABOX-315 |
LABOX-325 |
LABOX-350 |
Maximum pressure |
10kN |
30kN |
Z-axis stroke |
50 mm(open height 150 mm) |
80 mm(open height 200 mm) |
Stage size |
φ 70 mm |
φ 90 mm |
Maximum temperature |
2,500℃(2,200℃ for normal use)* |
Vacuum Pumping System |
Rotary Pump(Ultimate Vacuum; 6 Pa) |
Maximum pulse current output |
1000A |
2500A |
1500A |
2500A |
5000A |
※Maximum temperature is limited by the conditions, such as material composition,
sintering die & punch dimensions and holding time.
Medium Size SPS System
General-purpose SPS system for R&D to Trial Manufacture of Products
![](img/e_prd_img4.jpg) |
|
![](img/e_prd_img5.jpg) |
LABOX-625 Type-S(with optional unit) |
|
LABOX-1575(with optional unit)
|
|
![](img/e_prd_img6.jpg) |
|
![](img/e_prd_img7.jpg) |
φ70 mm Sinterd Compact |
|
Trial Manufacture of Products
|
|Main Specification|
Model Name |
LABOX-625 |
LABOX-650 |
LABOX-675 |
Chamber Type |
Type S : Standard Model Vertical Semicircle Cylinder-shaped Chamber
Type F : Horizontal Cylinder and Forward Door Type Chamber |
Maximum pressure |
60kN |
Z-axis stroke |
150 mm(open height 250 mm) |
Stage size |
φ 90 mm |
Maximum temperature |
2,500℃(2,200℃ for normal use)* |
Vacuum Pumping System |
Rotary Pump(Ultimate Vacuum; 6 Pa) |
Maximum pulse current output |
2500A |
5000A |
7500A |
Model Name |
LABOX-1550
|
LABOX-1575 |
LABOX-1510k |
LABOX-3050 |
LABOX-3075 |
LABOX-3010k |
Maximum pressure |
150kN |
300kN |
Z-axis stroke |
150 mm(open height 250 mm) |
180 mm(open height 280 mm) |
Stage size |
φ 150 mm |
φ 200 mm |
Maximum temperature |
2,500℃(2,200℃ for normal use)* |
Vacuum Pumping System |
Rotary Pump & Mechanical Booster Pumps( Ultimate Vacuum; 6 Pa) |
Maximum pulse current output |
5000A |
7500A |
10000A |
5000A |
7500A |
1000A |
※Maximum temperature is limited by the conditions, such as material composition,
sintering die & punch dimensions and holding time.
